- Breakers, Contactor
CHINT Contactor 80A AC3 3P 1NA+1NC NC1-8011 380V 50/60HZ
Brand Name: Chint
Main Circuit Rating Current: 80A
Number of Pole: 3
Phase: 3/4
Main Circuit Rating Voltage: 380V
Model Number: NXC-22 220V
Electricity Type: AC
Frequency: 50/60Hz
Rated breaking capacity: Breaking current: 8 Ie (AC-3) or 10 Ie (AC-4)
Size: 70*126.5*75mm
Place of Origin: ChinaSKU: n/a - Industrial Materials, Transformer Accessories
Chint Current Transformer – Accurate Current Monitoring Systems
Industrial Materials, Transformer AccessoriesChint Current Transformer – Accurate Current Monitoring Systems
Features:
Wide Current Range: Available in multiple primary current ratings to suit various applications.
High Accuracy: Ensures precise current measurement for metering and protection.
Compact & Durable Design: Built with quality materials for reliable long-term performance.
Easy Installation: Supports both bus bar and cable mounting options.
Insulation & Safety: Fully enclosed housing ensures electrical insulation and safety.
Standard Compliance: Meets IEC 61869 standards for current transformers.SKU: n/a - Breakers, Residual Current Breaker with Over-Current (RCBO)
Chint Electric NXBLE 4 Pole 30mA-6kA-RCBO – Reliable Protection
Breakers, Residual Current Breaker with Over-Current (RCBO)Chint Electric NXBLE 4 Pole 30mA-6kA-RCBO – Reliable Protection
Technical Specifications
Brand: Chint
Model: NXBLE Series
Type: RCBO (Residual Current Breaker with Over current Protection)
Rated Current (In): 6A – 63A (varies by model)
Rated Voltage (Un): 230/240V AC, 50/60Hz
Breaking Capacity: 6kA / 10kA (model-dependent)
Residual Current Sensitivity (I∆n): 30mA, 100mA, 300mA
Poles: 1P+N (single phase)
Tripping Curve: B or C curve
Standards Compliance: IEC/EN 61009-1SKU: n/a - Breakers, Contactor
Chint NC1 Series 45A 4Pole Contactor
Technical Specifications
Model: NC1-45 (specific model may vary with auxiliary contacts and coil voltage, e.g., NC1-2504)
Rated Current (AC-1): 45A
Number of Poles: 4P (Four Main Poles)
Rated Operational Voltage (Ue): Up to 690V AC
Rated Insulation Voltage (Ui): 690V AC
Utilization Category: AC-1, AC-3
Coil Voltage: Available in various AC voltages (e.g., 24V, 48V, 110V, 230V, 415V)
Frequency: 50/60Hz
Mechanical Life: Up to 10,000,000 cycles
Electrical Life: Varies based on load and operating conditions
Mounting: DIN Rail or screw mounting
Ambient Temperature: −5∘C to +40∘C
Standard: IEC/EN 60947-4-1SKU: n/a - 63Amp Change Over Switch, Change Over & Gear Switch, Change Over Switch
CHINT NH40 Manual Changeover Switch 63A 4P Rotary Handle
63Amp Change Over Switch, Change Over & Gear Switch, Change Over SwitchCHINT NH40 Manual Changeover Switch 63A 4P Rotary Handle
Brand Name: CHINT
Rated Current: 63A
Number of Pole: 4
Model Number: NH40
Max. Voltage: AC440V
Operation type: Manual Change Over Switch
Certificate: CE ISO
Warranty: 2 Years
Place of Origin: Zhejiang, ChinaSKU: n/a - Breakers, RCCB, Residual Current Breaker with Over-Current (RCBO)
CHINT NL1E-63 1P+N 40A 2P Residual Current Circuit Breaker
Breakers, RCCB, Residual Current Breaker with Over-Current (RCBO)CHINT NL1E-63 1P+N 40A 2P Residual Current Circuit Breaker
Brand: Chint Electric
Nominal current: 40 A
Product type: RCCB
Model: NL1-63
Number of poles: 1P+N (2 Pole)
Rated residual operating current: 0.01A, 0.03A
Thermal magnetic release: C, D
Mechanical life: 20000 cycles
Electrical life: 10000 cycles
Rated short-circuit breaking capacity(Icu): 6000A
Rated impulse withstand voltage(Uimp): 4kV
Rated voltage: 230V ~
Frequency: 50Hz
Dim: (L x W x H) 79 x 36 x 86 mm
Country of Origin: ChinaSKU: n/a - Breakers, Soft Stater
Chint NQ3-5.5P Direct On-Line Starter 7-10A
Technical Specifications – Chint NQ3-5.5P DOL Starter
Brand: Chint
Series: NQ3
Model Number: NQ3-5.5P
Type: Direct On-Line (DOL) Starter
Category: Manual Motor Starter
Power Rating: 5.5 kW
Rated Current Range: 7 – 10A
Rated Input Voltage: 220V AC
Rated Impulse Withstand Voltage (Uimp): 6 kV
Poles: 3P (Three-phase application compatible)
Frequency: 50/60 Hz
Control Function: Manual start/stop operation
Ambient Operating Temperature: -5°C to +40°C
Application: Industrial and commercial motor starting
Protection: Overload and surge protection
Construction: Compact, durable, and user-friendly design
Compliance: IEC/EN 60947 standards
SKU: n/a - Breakers, SPD, Surge Protective Device SPD
Chint NU6-II-G/F-3PN Lightning Arrester Protector Breaker 4 Pole
Breakers, SPD, Surge Protective Device SPDChint NU6-II-G/F-3PN Lightning Arrester Protector Breaker 4 Pole
Brand: Chint Electric
Amps: 125A/160A
Test class: I, II
Rate maximum continuous operational voltage: 275V, 385V
Poles: 1P+N, 2P+N, 3P+N
Protection mode: L-PE, L-N, N-PE
Maximum discharge current（8/20μs）Imax: 50kA
Level of protection Up: 1.5kV for 275V; 1.8kV for 385V
Alternative function: Remote indication contact
Ambient temperature: -40 to +70°C
Electric ratings: 230/400V, AC50Hz;
Standard: IEC/EN 61643-11
Application: Protect electric system and on-loading electrical apparatus from thunder and instantaneous over-voltageSKU: n/a - Breakers, MCB, Two Poles MCB
Chint NXB-125 2p 100A DC Miniature Circuit Breaker
Brand: Chint
Model: NXB-125
Current Amps: 100A
No of Poles: 2
Type: DC MCB
Breaking capacity: 10KA
ON/OFF Control Type: Handle Toggle
Mounting Method: Din Rail Mounting
Connection Type: Screw terminals
C curve (Electro Magnetic 5 In~10 In)
Conform to SNI Standard 04-6507.1-2002, IEC/EN 60898-1
Voltage (V): 220 VAC Current
Warranty: 1 year
Country of Origin: ChinaSKU: n/a - Breakers, MCB, MCB & MCCB, Two Poles MCB
Chint NXB-125 2p 125A DC Miniature Circuit Breaker Original
Brand: Chint
Model: NXB-125
Current Amps: 125A
No of Poles: 2
Type: DC MCB
Breaking capacity: 10KA
ON/OFF Control Type: Handle Toggle
Mounting Method: Din Rail Mounting
Connection Type: Screw terminals
C curve (Electro Magnetic 5 In~10 In)
Conform to SNI Standard 04-6507.1-2002, IEC/EN 60898-1
Voltage (V): 220 VAC Current
Warranty: 1 year
Country of Origin: ChinaSKU: n/a - Breakers, Four Poles MCCB, MCB & MCCB, MCCB
Chint NXM 4 Pole 100Amp MCCB Molded Case Circuit Breaker
Brand: Chint Electric
Current Rating: 100A
No of Poles: 4
Type: MCCB
Model: NXM
Breaking capacity: up to 10kA
Breaking capacity code: E, S, F, H
Adjustable: No
Mounting Style: Fixed plug-in type
Voltage: 220-240V AC
Input Frequency: 50/60 Hz
Common mounting dimension
Warranty: 1 year
Country of Origin: ChinaSKU: n/a - Breakers, MCB & MCCB, MCCB, Three Poles MCCB
Chint NXMS 320A 3-Pole MCCB Molded Case Circuit Breaker
Brand: Chint Electric
Current Rating: 320A
No of Poles: 3
Type: MCCB
Model: NXM
Breaking capacity: up to 36kA
Breaking capacity code: E, S, F, H
Adjustable: No
Mounting Style: Fixed plug-in type
Voltage: 220-240V AC
Input Frequency: 50/60 Hz
Common mounting dimension
Warranty: 1 year
Country of Origin: ChinaSKU: n/a - Breakers, Four Poles MCCB, MCB & MCCB, MCCB
Chint NXMS 320A 4-Pole MCCB Molded Case Circuit Breaker
Brand: Chint Electric
Current Rating: 320A
No of Poles: 4
Type: MCCB
Model: NXM
Breaking capacity: up to 36kA
Breaking capacity code: E, S, F, H
Adjustable: No
Mounting Style: Fixed plug-in type
Voltage: 220-240V AC
Input Frequency: 50/60 Hz
Common mounting dimension
Warranty: 1 year
Country of Origin: ChinaSKU: n/a - Breakers, Soft Stater
Chint Push Button Start & Stop – Control for Electrical Circuits
Features:
Dual Functionality: Separate Start (Green) and Stop (Red) buttons for intuitive operation.
Durable Construction: Made from high-quality thermoplastic and metal components for long service life.
Panel Mount Design: Fits standard 22mm or 30mm cutouts, ideal for control panels and operator stations.
NO & NC Contact Blocks: Supports Normally Open (NO) and Normally Closed (NC) configurations for flexible wiring.
Mechanical Durability: Designed for high-frequency use in industrial applications.
Clear Markings: Color-coded and labeled for quick identification and safety.SKU: n/a - Breakers, RCCB, Residual Current Breaker with Over-Current (RCBO)
Chint RCCB NL1-63 63A 2P Residual Current Circuit Breaker
Breakers, RCCB, Residual Current Breaker with Over-Current (RCBO)Chint RCCB NL1-63 63A 2P Residual Current Circuit Breaker
Brand: Chint Electric
Nominal current: 63 A
Product type: RCCB
Model: NL1-63
Number of poles: 1P+N (2 Pole)
Rated residual operating current: 0.01A, 0.03A
Thermal magnetic release: C, D
Mechanical life: 20000 cycles
Electrical life: 10000 cycles
Rated short-circuit breaking capacity(Icu): 6000A
Rated impulse withstand voltage(Uimp): 4kV
Rated voltage: 230V ~
Frequency: 50Hz
Dim: (L x W x H) 79 x 36 x 86 mm
Country of Origin: ChinaSKU: n/a - Breakers, SPD, Surge Protective Device SPD
Chint Surge Arrestor Device SPD NU6-II-G/F-1PN 2 Pole
Brand: Chint Electric
Amps: 125A/160A
Test class: I, II
Rate maximum continuous operational voltage: 275V, 385V
Poles: 1P+N, 2P+N, 3P+N
Protection mode: L-PE, L-N, N-PE
Maximum discharge current（8/20μs）Imax: 50kA
Level of protection Up: 1.5kV for 275V; 1.8kV for 385V
Alternative function: Remote indication contact
Ambient temperature: -40 to +70°C
Electric ratings: 230/400V, AC50Hz;
Standard: IEC/EN 61643-11
Application: Protect electric system and on-loading electrical apparatus from thunder and instantaneous over-voltageSKU: n/a - Breakers, SPD, Surge Protective Device SPD
Chint Surge Protective Device SPD NU6-II-G/F-3 Pole
Brand: Chint Electric
Amps: 125A/160A
Test class: I, II
Rate maximum continuous operational voltage: 275V, 385V
Poles: 1P+N, 2P+N, 3P+N
Protection mode: L-PE, L-N, N-PE
Maximum discharge current（8/20μs）Imax: 50kA
Level of protection Up: 1.5kV for 275V; 1.8kV for 385V
Alternative function: Remote indication contact
Ambient temperature: -40 to +70°C
Electric ratings: 230/400V, AC50Hz;
Standard: IEC/EN 61643-11
Application: Protect electric system and on-loading electrical apparatus from thunder and instantaneous over-voltageSKU: n/a
